Creating an External Replica of AWS Aurora MySQL with Mydumper

Oftentimes, we need to replicate between Amazon Aurora and an external MySQL server. The idea is to start by taking a point-in-time copy of the dataset. Next, we can configure MySQL replication to roll it forward and keep the data up-to-date.

This process is documented by Amazon, however, it relies on the mysqldump method to create the initial copy of the data. If the dataset is in the high GB/TB range, this single-threaded method could take a very long time. Similarly, there are ways to improve the import phase (which can easily take 2x the time of the export).

Let’s explore some tricks to significantly improve the speed of this process.

Preparation Steps

The first step is to enable binary logs in Aurora. Go to the Cluster-level parameter group and make sure binlog_format is set to ROW. There is no log_bin option in Aurora (in case you are wondering), simply setting binlog_format is enough. The change requires a restart of the writer instance, so it, unfortunately, means a few minutes of downtime.

We can check if a server is generating binary logs as follows:

mysql> SHOW MASTER LOGS;

+----------------------------+-----------+
| Log_name                   | File_size |
+----------------------------+-----------+
| mysql-bin-changelog.034148 | 134219307 |
| mysql-bin-changelog.034149 | 134218251 |
...

Otherwise, you will get an error:

ERROR 1381 (HY000): You are not using binary logging

We also need to ensure a proper binary log retention period. For example, if we expect the initial data export/import to take one day, we can set the retention period to something like three days to be on the safe side. This will help ensure we can roll forward the restored data.

mysql> call mysql.rds_set_configuration('binlog retention hours', 72);
Query OK, 0 rows affected (0.27 sec)

mysql> CALL mysql.rds_show_configuration;
+------------------------+-------+------------------------------------------------------------------------------------------------------+
| name                   | value | description                                                                                          |
+------------------------+-------+------------------------------------------------------------------------------------------------------+
| binlog retention hours | 72    | binlog retention hours specifies the duration in hours before binary logs are automatically deleted. |
+------------------------+-------+------------------------------------------------------------------------------------------------------+
1 row in set (0.25 sec)

The next step is creating a temporary cluster to take the export. We need to do this for a number of reasons: first to avoid overloading the actual production cluster by our export process, also because mydumper relies on FLUSH TABLES WITH READ LOCK to get a consistent backup, which in Aurora is not possible (due to the lack of SUPER privilege).

Go to the RDS console and restore a snapshot that was created AFTER the date/time where you enabled the binary logs. The restored cluster should also have binlog_format set, so select the correct Cluster parameter group.

Next, capture the binary log position for replication. This is done by inspecting the Recent events section in the console. After highlighting your new temporary writer instance in the console, you should see something like this:

Binlog position from crash recovery is mysql-bin-changelog.034259 32068147

So now we have the information to prepare the CHANGE MASTER command to use at the end of the process.

Exporting the Data

To get the data out of the temporary instance, follow these steps:

  1. Backup the schema
  2. Save the user privileges
  3. Backup the data

This gives us added flexibility; we can do some schema changes, add indexes, or extract only a subset of the data.

Let’s create a configuration file with the login details, for example:

tee /backup/aurora.cnf <<EOF
[client]
user=percona
password=percona
host=percona-tmp.cgutr97lnli6.us-west-1.rds.amazonaws.com
EOF

For the schema backup, use mydumper to do a no-rows export:

mydumper --no-data \
--triggers \
--routines \
--events \
-v 3 \
--no-locks \
--outputdir /backup/schema \
--logfile /backup/mydumper.log \
--regex '^(?!(mysql|test|performance_schema|information_schema|sys))' \
--defaults-file /backup/aurora.cnf

To get the user privileges I normally like to use pt-show-grants. Aurora is, however, hiding the password hashes when you run SHOW GRANTS statement, so pt-show-grants will print incomplete statements e.g.:

mysql> SHOW GRANTS FOR 'user'@'%';
+---------------------------------------------------------+
| Grants for user@%                                       |
+---------------------------------------------------------+
| GRANT USAGE ON *.* TO 'user'@'%' IDENTIFIED BY PASSWORD |
| GRANT SELECT ON `db`.* TO 'user'@'%'                    |
+---------------------------------------------------------+

We can still gather the hashes and replace them manually in the pt-show-grants output if there is a small-ish number of users.

pt-show-grants --user=percona -ppercona -hpercona-tmp.cgutr97lnli6.us-west-1.rds.amazonaws.com  > grants.sql

mysql> select user, password from mysql.user;

Finally, run mydumper to export the data:

mydumper -t 8 \
--compress \
--triggers \
--routines \
--events \
—-rows=10000000 \
-v 3 \
--long-query-guard 999999 \
--no-locks \
--outputdir /backup/export \
--logfile /backup/mydumper.log \
--regex '^(?!(mysql|test|performance_schema|information_schema|sys))' \
-O skip.txt \
--defaults-file /backup/aurora.cnf

The number of threads should match the number of CPUs of the instance running mydumper. In the skip.txt file, you can include any tables that you don’t want to copy. The –rows argument will give you the ability to split tables in chunks of X number of rows. Each chunk can run in parallel, so it is a huge speed bump for big tables.

Importing the Data

We need to stand up a MySQL instance to do the data import. In order to speed up the process as much as possible, I suggest doing a number of optimizations to my.cnf as follows:

[mysqld]
pid-file=/var/run/mysqld/mysqld.pid
log-error=/var/log/mysqld.log
datadir=/var/lib/mysql
socket=/var/lib/mysql/mysql.sock
log_slave_updates
innodb_buffer_pool_size=16G
binlog_format=ROW
innodb_log_file_size=1G
innodb_flush_method=O_DIRECT
innodb_flush_log_at_trx_commit=0
server-id=1000
log-bin=/log/mysql-bin
sync_binlog=0
master_info_repository=TABLE
relay_log_info_repository=TABLE
query_cache_type=0
query_cache_size=0
innodb_flush_neighbors=0
innodb_io_capacity_max=10000
innodb_stats_on_metadata=off
max_allowed_packet=1G
net_read_timeout=60
performance_schema=off
innodb_adaptive_hash_index=off
expire_logs_days=3
sql_mode=NO_ENGINE_SUBSTITUTION
innodb_doublewrite=off

Note that mydumper is smart enough to turn off the binary log for the importer threads.

After the import is complete, it is important to revert these settings to “safer” values: innodb_doublewriteinnodb_flush_log_at_trx_commit, sync_binlog, and also enable performance_schema again.

The next step is to create an empty schema by running myloader:

myloader \
-d /backup/schema \
-v 3 \
-h localhost \
-u root \
-p percona

At this point, we can easily introduce modifications like adding indexes, since the tables are empty. We can also restore the users at this time:

(echo "SET SQL_LOG_BIN=0;" ; cat grants.sql ) | mysql -uroot -ppercona -f

Now we are ready to restore the actual data using myloader. It is recommended to run this inside a screen session:

myloader -t 4 \
-d /backup/export \
-q 100 \
-v 3 \
-h localhost \
-u root \
-p percona

The rule of thumb here is to use half the number of vCPU threads. I also normally like to reduce mydumper default transaction size (1000) to avoid long transactions, but your mileage may vary.

After the import process is done, we can leverage faster methods (like snapshots or Percona Xtrabackup) to seed any remaining external replicas.

Setting Up Replication

The final step is setting up replication from the actual production cluster (not the temporary one!) to your external instance.

It is a good idea to create a dedicated user for this process in the source instance, as follows:

CREATE USER 'repl'@'%' IDENTIFIED BY 'password';
GRANT REPLICATION SLAVE ON *.* TO 'repl'@'%';

Now we can start replication, using the binary log coordinates that we captured before:

CHANGE MASTER TO MASTER_HOST='aurora-cluster-gh5s6lnli6.us-west-1.rds.amazonaws.com', MASTER_USER='repl', MASTER_PASSWORD='percona', MASTER_LOG_FILE='mysql-bin-changelog.034259', MASTER_LOG_POS=32068147;
START SLAVE;

Final Words

Unfortunately, there is no quick and easy method to get a large dataset out of an Aurora cluster. We have seen how mydumper and myloader can save a lot of time when creating external replicas, by introducing parallel operations. We also reviewed some good practices and configuration tricks for speeding up the data loading phase as much as possible.


Optimize your database performance with Percona Monitoring and Management, a free, open source database monitoring tool. Designed to work with Amazon RDS MySQL and Amazon Aurora MySQL with a specific dashboard for monitoring Amazon Aurora MySQL using Cloudwatch and direct sampling of MySQL metrics.

Visit the Demo

Nov
12
2015
--

Logical MySQL backup tool Mydumper 0.9.1 now available

Databases backupThe new Mydumper 0.9.1 version, which includes many new features and bug fixes, is now available.  You can download the code from here.

A significant change included in this version now enables Mydumper to handle all schema objects!!  So there is no longer a dependency on using mysqldump to ensure complex schemas are backed up alongside the data.

Let’s review some of the new features:

Full schema support for Mydumper/Myloader

Mydumper now takes care of backing up the schema, including Views and Merged tables. As a result, we now have these new associated options:

-d, --no-data Do not dump table data
-G, --triggers Dump triggers
-E, --events Dump events
-R, --routines Dump stored procedures and functions

These options are not enabled by default to keep backward compatibility with actual mixed solutions using Mysqldump for DDLs.

Locking reduce options

--trx-consistency-only      Transactional consistency only

You can think on this as --single-transaction for mysqldump, but still with binlog position. Obviously this position only applies to transactional tables (TokuDB included).  One of the advantages of using this option is that the global read lock is only held for the threads coordination, so it’s released as soon as the transactions are started.

GTIDs and Multisource Slave

GTIDs are now recorded on the metadata file.  Also Mydumper is now able to detect a multisource slave (MariaDB 10.1.x) and will record all the slaves coordinates.

Myloader single database restore

Until now the only option was to copy the database files to a different directory and restore from it. However, we now have a new option available:

-s, --source-db                   Database to restore

It can be used also in combination with -B, --database to restore to a different database name.

Full list of Bug Fixes:

#1431410 innodb stats tables
#1440403 *-post and *-triggers compressed files corrupt
#1470891 functions may be needed by SP and views
#1390437 segmentation fault against Percona MySQL 5.6.15-63.0
#1446280 Segmentation fault on Debian Wheezy
#1399715 Typo in –tables-list option in manpage
#1428608 missing -K option in mydumper manpage
#1440437 myloader: wrong database name in message when -B used
#1457091 tokudb detection doesn’t work
#1481747 Unable to compile r179 WITH_BINLOG=ON (undeclared ‘bj’)
#1507574 Assertion when broken mrg tables
#841651 dump view definitions
#1485688 make compile error myloader.c:209



The post Logical MySQL backup tool Mydumper 0.9.1 now available appeared first on MySQL Performance Blog.

Sep
21
2015
--

Containing your logical backups: mydumper in docker

Even with software like Percona Xtrabackup, logical backups remain an important component of a thorough backup strategy. To gather a logical backup in a timely fashion we rely on a tool called mydumper. In the Percona Managed Services department we’re lucky enough to have one of the project’s most active contributors and many of the latest features and bug fixes have been released to satisfy some of our own use cases. Compiling mydumper remains one of my personal bug bears and undoubtedly the highest barrier to entry for many potential adopters. There are a few conditions that make compiling it difficult, tiring or even prohibitive. The open source logical backup tool does not supply any official packages, however our friends over at TwinDB are currently shipping a package for CentOS/RHEL. So what if you’re running something else, like Debian, Ubuntu, Arch? Well recently I had a flash of inspiration.

Since I’ve been turning some ideas into docker containers, it dawned on me that it would be a trivial image to create and would add instant portability to the binaries. With a docker environment you can take an image and run a logical backup through to a mapped volume. It’s almost as easy as that.

mydumper_docker

So let me show you what I mean. I have built a docker image with the mydumper, myloader and mysql client libraries installed and it’s available for you on docker hub. This means that we can call a new container to make our backup without technically installing mydumper anywhere. This can get you from zero to mydumper very fast if there are hurdles in your way to deploying the open source backup tool into production.

With the grand assumption that you’ve got Docker installed somewhere, lets pull the image from the docker hub

docker pull mysqlboy/mydumper

Once all the layers download (it’s < 200MB) you’re all set to launch a backup using the mydumper binary. You can roll your own command but it could look similar to;

docker run
--name mydumper
--rm
-v {backup_parent_dir}:/backups
mysqlboy/mydumper
mydumper
--host={host_ipaddr}
--user={mysql_username}
--password={mysql_password}
--outputdir=/backups
--less-locking
--compress
--use-savepoints

If you’re unfamiliar with Docker itself; a very high level summary for you; Docker is a product intended to facilitate process isolation or ‘micro services’ known as containerization. It intends to be lighter and more efficient than Virtual Machines as we traditionally know them. There’s much more to this work flow than I intend to explain here but please see the further learning section in the footer.

Let me explain a little of the above call. We want to launch a mydumper run isolated to a container. We are giving the docker daemon the instruction to remove the container after it finishes it’s run (–rm), we are calling the container to be an ‘instance’ of the mysqlboy/mydumper image and we are passing a traditional mydumper command as the container’s instruction. We have mapped a location on the local filesystem into the container to ensure that the backup persists after the container is stopped and removed. The mydumper command itself will make a full backup of the instance you point it to (mydumper can make remote backups, pulling the data locally) and will use the less locking, savepoints and compression features.

What’s more, the beauty of containerizing the mydumper/myloader binaries mean that you can use this image in conjunction with docker machine to source logical backups from Mac and Windows where this process is typically difficult to assume.

I’m going to be filling in for my colleague Max Bubenick this week at Percona Live in Amsterdam talking about Logical Backups using Mydumper and if you’re planning to attend, the mydumper docker image will provide you with a quick path to trial. Thanks for reading and if you’re in Amsterdam this week don’t forget to say hello!

Further learning about docker:

https://www.docker.com/whatisdocker

https://www.youtube.com/user/dockerrun

http://europe-2015.dockercon.com/

The post Containing your logical backups: mydumper in docker appeared first on MySQL Performance Blog.

Jan
21
2015
--

Importing big tables with large indexes with Myloader MySQL tool

Mydumper is known as the faster (much faster) mysqldump alternative. So, if you take a logical backup you will choose Mydumper instead of mysqldump. But what about the restore? Well, who needs to restore a logical backup? It takes ages! Even with Myloader. But this could change just a bit if we are able to take advantage of Fast Index Creation.

As you probably know, Mydumper and mysqldump export the struct of a table, with all the indexes and the constraints, and of course, the data. Then, Myloader and MySQL import the struct of the table and import the data. The most important difference is that you can configure Myloader to import the data using a certain amount of threads. The import steps are:

  1. Create the complete struct of the table
  2. Import the data

When you execute Myloader, internally it first creates the tables executing the “-schema.sql” files and then takes all the filenames without “schema.sql” and puts them in a task queue. Every thread takes a filename from the queue, which actually is a chunk of the table, and executes it.  When finished it takes another chunk from the queue, but if the queue is empty it just ends.

This import procedure works fast for small tables, but with big tables with large indexes the inserts are getting slower caused by the overhead of insert the new values in secondary indexes. Another way to import the data is:

  1. Split the table structure into table creation with primary key, indexes creation and constraint creation
  2. Create tables with primary key
  3. Per table do:
    1. Load the data
    2. Create index
  4. Create constraints

This import procedure is implemented in a branch of Myloader that can be downloaded from here or directly executing bzr with the repository:

bzr branch lp:~david-ducos/mydumper/mydumper

The tool reads the schema files and splits them into three separate statements which create the tables with the primary key, the indexes and the constraints. The primary key is kept in the table creation in order to avoid the recreation of the table when a primary key is added and the “KEY” and “CONSTRAINT” lines are removed. These lines are added to the index and constraint statements, respectively.

It processes tables according to their size starting with the largest because creating the indexes of a big table could take hours and is single-threaded. While we cannot process other indexes at the time, we are potentially able to create other tables with the remaining threads.

It has a new thread (monitor_process) that decides which chunk of data will be put in the task queue and a communication queue which is used by the task processes to tell the monitor_process which chunk has been completed.

I run multiple imports on an AWS m1.xlarge machine with one table comparing Myloader and this branch and I found that with large indexes the times were:

myloader

As you can see, when you have less than 150M rows, import the data and then create the indexes is higher than import the table with the indexes all at once. But everything changes after 150M rows, import 200M takes 64 minutes more for Myloader but just 24 minutes for the new branch.

On a table of 200M rows with a integer primary key and 9 integer columns, you will see how the time increases as the index gets larger:

myloader2

Where:

2-2-0: two 1-column and two 2-column index
2-2-1: two 1-column, two 2-column and one 3-column index
2-3-1: two 1-column, three 2-column and one 3-column index
2-3-2: two 1-column, three 2-column and two 3-column index

Conclusion

This branch can only import all the tables with this same strategy, but with this new logic in Myloader, in a future version it could be able to import each table with the best strategy reducing the time of the restore considerably.

The post Importing big tables with large indexes with Myloader MySQL tool appeared first on MySQL Performance Blog.

Jan
14
2015
--

MySQL performance implications of InnoDB isolation modes

Over the past few months I’ve written a couple of posts about dangerous debt of InnoDB Transactional History and about the fact MVCC can be the cause of severe MySQL performance issues. In this post I will cover a related topic – InnoDB Transaction Isolation Modes, their relationship with MVCC (multi-version concurrency control) and how they impact MySQL performance.

The MySQL Manual provides a decent description of transaction isolation modes supported by MySQL – I will not repeat it here but rather focus on performance implications.

SERIALIZABLE – This is the strongest isolation mode to the point it essentially defeats Multi-Versioning making all SELECTs locking causing significant overhead both in terms of lock management (setting locks is expensive) and the concurrency you can get. This mode is only used in very special circumstances among MySQL Applications.

REPEATABLE READ – This is default isolation level and generally it is quite nice and convenient for the application. It sees all the data at the time of the first read (assuming using standard non-locking reads). This however comes at high cost – InnoDB needs to maintain transaction history up to the point of transaction start, which can be very expensive. The worse-case scenario being applications with a high level of updates and hot rows – you really do not want InnoDB to deal with rows which have hundreds of thousands of versions.

In terms of performance impact, both reads and writes can be impacted. For select queries traversing multiple row versions is very expensive but so it is also for updates, especially as version control seems to cause severe contention issues in MySQL 5.6

Here is example: I ran sysbench for a completely in-memory data set and when start transaction and run full table scan query couple of times while keeping transaction open:

sysbench  --num-threads=64 --report-interval=10 --max-time=0 --max-requests=0 --rand-type=pareto --oltp-table-size=80000000 --mysql-user=root --mysql-password= --mysql-db=sbinnodb  --test=/usr/share/doc/sysbench/tests/db/update_index.lua run

As you can see the write throughput drops drastically and stays low at all times when transaction is open, and not only when the query is running. This is perhaps the worse-case scenario I could find which happens when you have select outside of transaction followed by a long transaction in repeatable-read isolation mode. Though you can see regression in other cases, too.

Here is the set of queries I used if someone wants to repeat the test:

select avg(length(c)) from sbtest1;
begin;
select avg(length(c)) from sbtest1;
select sleep(300);
commit;

Not only is Repeatable Read the default isolation level, it is also used for logical backups with InnoDB – think mydumper or mysqldump –single-transaction
These results show such backup methods not only can’t be used with large data sets due to long recovery time but also can’t be used with some high write environments due to their performance impact.

READ COMMITTED mode is similar to REPEATABLE READ with the essential difference being what versions are not kept to the start of first read in transaction, but instead to the start of the current statement. As such using this mode allows InnoDB to maintain a lot less versions, especially if you do not have very long running statements. If you have some long running selects – such as reporting queries performance impact can be still severe.

In general I think good practice is to use READ COMITTED isolation mode as default and change to REPEATABLE READ for those applications or transactions which require it.

READ UNCOMMITTED – I think this is the least understood isolation mode (not a surprise as it only has 2 lines of documentation about it) which only describe it from the logical point of view. If you’re using this isolation mode you will see all the changes done in the database as they happen, even those by transactions which have not been yet committed. One nice use case for this isolation mode is what you can “watch” as some large scale UPDATE statements are happening with dirty reads showing which rows have already been changes and which have not.

So this statement shows changes that have not been committed yet and might not ever be committed if the transaction doing them runs into some errors so – this mode should be used with extreme care. There are a number of cases though when we do not need 100% accurate data and in this case this mode becomes very handy.

So how does READ UNCOMMITTED behave from a performance point of view? In theory InnoDB could purge row versions even if they have been created after the start of the statement in READ UNCOMMITTED mode. In practice, due to a bug or some intricate implementation detail it does not do that – row versions still will be kept to the start of the statement. So if you run very long running SELECT in READ UNCOMMITTED statements you will get a large amount of row versions created, just as if you would use READ COMMITTED. No win here.

There is an important win from SELECT side – READ UNCOMMITTED isolation mode means InnoDB never needs to go and examine the older row versions – the last row version is always the correct one which can cause dramatic performance improvement especially if the undo space had spilled over to the disk so finding old row versions can cause a lot of IO.

Perhaps the best illustration I discovered with query select avg(k) from sbtest1; ran in parallel with the same update heavy workload stated above. In READ COMMITTED isolation mode it never completes – I assume because new index entries are inserted faster than they are scanned, in case of READ UNCOMMITTED isolation mode it completes in a minute or so.

Final Thoughts: Using InnoDB Isolation modes correctly can help your application to get the best possible performance. Your mileage may vary and in some cases you will see no difference; in others it will be absolutely dramatic. There also seems to be a lot of work to be done in relationship to InnoDB performance with long version history. I hope it will be tackled in the future MySQL version.

The post MySQL performance implications of InnoDB isolation modes appeared first on MySQL Performance Blog.

Jun
13
2014
--

mydumper [less] locking

In this post I would like to review how my dumper for MySQL works from the point of view of locks. Since 0.6 serie we have different options, so I will try to explain how they work

As you may know mydumper is multithreaded and this adds a lot of complexity compared with other logical backup tools as it also needs to coordinate all threads with the same snapshot to be consistent. So let review how mydumper does this with the default settings.

By default mydumper uses 4 threads to dump data and 1 main thread

Main Thread

  • FLUSH TABLES WITH READ LOCK
Dump Thread X

  • START TRANSACTION WITH CONSISTENT SNAPSHOT;
  • dump non-InnoDB tables
Main Thread

  • UNLOCK TABLES
Dump Thread X

  • dump InnoDB tables
As you can see in this case we need FTWRL for two things, coordinate transaction’s snapshots and dump non-InnoDB tables in a consistent way. So we have have global read lock until we dumped all non-InnoDB tables.
What less locking does is this:
Main Thread

  • FLUSH TABLES WITH READ LOCK
Dump Thread X

  • START TRANSACTION WITH CONSISTENT SNAPSHOT;
 LL Dump Thread X

  • LOCK TABLES non-InnoDB
Main Thread

  • UNLOCK TABLES
 LL Dump Thread X

  • dump non-InnoDB tables
  • UNLOCK non-InnoDB
Dump Thread X

  • dump InnoDB tables

So now the global read lock its in place until less-locking threads lock non-InnoDB tables, and this is really fast. The only downsize is that it uses double the amount of threads, so for the default (4 threads) we will end up having 9 connections, but always 4 will be running at the same time.

Less-locking really helps when you have MyISAM or ARCHIVE that are not heavily updated by production workload, also you should know that LOCK TABLE … READ LOCAL allows non conflicting INSERTS on MyISAM so if you use that tables to keep logs (append only) you will not notice that lock at all.

For the next release we will implement backup locks that will avoid us to run FTWRL.

The post mydumper [less] locking appeared first on MySQL Performance Blog.

Powered by WordPress | Theme: Aeros 2.0 by TheBuckmaker.com
